LCD 100A Contact Resistance Tester for Electrical Circuit Breaker Testing

Product Description

SXHL-100A Loop Resistance Tester

The SXHL-100A Loop Resistance Tester is designed to check the resistance of conductive paths in circuit breakers, busbars, and other electrical connection points. It helps engineers evaluate electrical contact conditions and supports routine inspection and maintenance of power equipment.

During testing, the instrument delivers stable constant current through the measured connection and determines its resistance from the voltage response. Four-terminal measurement technology helps minimize the influence of test lead resistance and improve measurement accuracy. The LCD touch screen provides an intuitive interface for test operation and result viewing, making the instrument suitable for laboratory and field testing.

Product Advantages

1. Four-terminal measurement technology helps improve accuracy when measuring low resistance electrical connections.
2. Stable constant current output provides consistent testing conditions for repeatable resistance measurements.
3. The LCD touch screen simplifies test setup and allows measurement results to be viewed directly.
4. The 100A test current is suitable for contact resistance inspection of circuit breakers, busbars, and other high current connections.

Application Scenarios

1. Circuit Breaker Contact Resistance Testing
2. Busbar Connection Resistance Inspection
3. Switchgear Maintenance and Testing
4. Substation Electrical Equipment Inspection
5. Power Distribution System Maintenance
6. Electrical Connection Quality Verification

FAQ

Q1: What is the SXHL-100A mainly used for?A: It is mainly used to measure contact resistance in circuit breakers, busbars, and other electrical connection points.

Q2: What is the benefit of four-terminal measurement?A: Four-terminal measurement separates the current and voltage measurement paths, helping reduce the influence of test lead resistance and improve measurement accuracy.

Q3: Why does the tester use constant current output?A: Stable constant current provides consistent test conditions, which helps obtain reliable and repeatable resistance measurements.

Q4: Can it be used for circuit breaker maintenance?A: Yes. It can be used to check the contact resistance of circuit breakers during routine inspection, maintenance, and testing.

Q5: How is the tester operated?A: The instrument uses an LCD touch screen, allowing users to control the test and view measurement results through an intuitive interface.
