Compact Solar Panel Battery Testing Device With Touch Screen Control
The SXDC-Z DC Power Supply Characteristic Tester is a professional battery test equipment designed for intelligent detection of lead-acid batteries, lithium batteries, and nickel-metal hydride batteries. Widely used in power systems, communication base stations, and industrial equipment, this device employs advanced AC internal resistance testing technology to quickly and accurately measure core battery parameters including internal resistance, voltage, and capacity while automatically assessing battery health status.
Key Features
- High-precision AC Testing: Advanced AC four-wire test method with internal resistance measurement error ≤0.5% and voltage measurement error ≤0.1%
- Multi-parameter Detection: Integrated testing of internal resistance, voltage, capacity, and health status (SOH) in one device
- Portable & Lightweight: Compact design weighing only 1.2kg with anti-slip hand grip for easy transport to high-altitude and confined spaces
- One-key Rapid Testing: 4.3-inch HD color screen with intuitive icon operation and one-second test results
- Automatic Status Judgment: Built-in intelligent analysis algorithm automatically determines battery condition and life level
Technical Specifications
| Parameter Item |
Specification |
| Test Battery Type |
Lead-acid, lithium battery (18650/pouch), Ni-MH/Ni-Cd |
| Measurement Range |
Voltage: 0~20V; Internal resistance: 0~2000mΩ |
| Measurement Accuracy |
Voltage: ±0.05%FS; Internal resistance: ±0.5%FS |
| Working Power |
DC 3.7V/5000mAh lithium battery |
| Charging Mode |
USB-C, charging time ≤2h |
| Continuous Working Time |
≥12h |
| Display Screen |
4.3-inch HD color LCD screen |
| Data Storage |
8G, support 64G U disk expansion |
| Host Size |
150×80×30mm |
| Net Weight |
1.2kg |
About Sansion Power Electric
Sansion Power Electric Co., Ltd was established in 2005 and specializes in the research, development, manufacturing, and marketing of power electrical testing products. With over 10 years of industry experience, our products are widely used in power electric, railroad, energy conservation and environment protection, water conservancy, petrochemical industry, aerospace and other critical sectors.
Main Product Categories
- HV Hipot Test Set System
- Transformer Test Equipment
- HV Switchgear Test Set
- Relay Protection Tester
- CT/PT Tester
- SF6/Oil Tester
- Transmission Line Test System
- Insulation Resistance Tester
- Earth Resistance Tester
Certifications
Packing & Delivery
Frequently Asked Questions
Q1: Is your company a sales company or a manufacturer?
A: Sansion Power Electric Co., Ltd. is an industrial and trade enterprise with its own factory, self-produced and self-sold. Founded in 2005, we have twenty years of production experience with reliable production lines, test rooms, and R&D centers.
Q2: Whether the goods are in stock, whether they can be customized, and how long the delivery time is?
A: We manufacture to order according to customer specifications using the latest technology. Delivery time is typically within 10 working days under normal circumstances.
Q3: Is the quality guaranteed?
A: We use imported components extensively and conduct three quality inspections before shipment. Export products are packed in non-fumigation wooden boxes.
Q4: What are the after-sales terms?
A: We offer free consulting service, one year warranty, and provide support through email communication, video calls, and on-site technical assistance to resolve any after-sales issues promptly.
Q5: What are the cooperative countries or regions?
A: Our products have been successfully exported to the United States, France, Brazil, Australia, Spain, Portugal, Oman, Russia, the Netherlands, Indonesia, Bangladesh, Saudi Arabia, Chile, Colombia, Panama, Malaysia and other countries and regions.
Q6: In which fields can your product be applied?
A: Our services span key industries including Power, Railway, Energy Conservation & Environmental Protection, Water Conservancy, Petrochemicals, and Aerospace. Many products incorporate advanced international technologies and rank among the best in China, having consistently excelled in national high-voltage testing competitions.
